Magnetic Switch Sensor Circuit
The magnetic switch sensor circuit detects changes in the magnetic field to control the action of the device. It opens or closes connections based on magnetic interactions and is commonly used in security systems, doors, and industrial applications for efficient switching.
Description
Magnetic switch sensor is a device that uses changes in a magnetic field to open or close a switch. When the magnetic field changes, a voltage is generated within the coil. This voltage turns the switch on or off, controlling the circuit.
Application:
The electronic parts of magnetic switch sensor are widely used in industrial systems, security systems and power systems. Also useful for smart homes. For example, these switches notice when a family member leaves and closes a door or window. Smart devices allow you to turn off appliances like AC and lights to save energy and improve safety.
Popular Part Number
Common chips include AH180N-WG-7, AH3774-P-B, DRV5032FBDBZR, and HAL1502SU-A. Let's take a quick look at these chips and their role in magnetic induction switches.
Let's start with the AH180N-WG-7. This part number model can handle vibrations up to ±5 mT and stays super steady within ±1 mT after, no matter the temperature-from freezing cold to pretty warm (-40°C to 85°C). Made by Diodes Incorporated, it's easy to mount and gives you lots of options in designs.
AH180N-WG-7
Now, Let's move on to AH3774-P-B, a 4mA maximum supply current adaptive broadcaster. It can manage a maximum supply of 4mA and handles different temperatures like a champ, from really chilly to super hot (-40°C to 125°C).
AH3774-P-B
These maestros-AH180N-WG-7 and AH3774-P-B-blender creativity and excellence under the Diodes Incorporated brand, prepared to enliven your work. They are excellent options for adding brightness to your projects.
Next, let's examine the DRV5032FBDBZR, an exceptional all-pole switch that senses magnetic sensitivity at ±4.8mT and releases at ±0.5mT. Thanks to TI's well-known Hall effect technology, it performs well in a wide range of applications and operates in the temperature range of -40°C to 85°C. Its variable polarity and surface mount design fit a wide range of designs perfectly, giving your creations the captivating charm of magnetism.
DRV5032FBDBZR
Rapid magnetic field detection is provided by the TDK HAL1502SU-A, which releases at -2.5 mT and triggers at 2.5 mT. It runs in the range of 2.7V to 24V. Concealed within a compact SOT-23-3 enclosure, it is perfect for your designs, functioning with dependable performance in temperatures ranging from -40°C to 70°C. Accept HAL1502SU-A to let the magnetic creativity run wild in your pursuits.
HAL1502SU-A
Our advantage:
- Excellent prices-much cheaper than other platforms.
- Ample stock-multiple channels for purchasing, ensuring a stable supply.
- Guaranteed product quality-supports third-party quality inspections, with a 90-day return or exchange policy for any issues within that timeframe.
- Rich experience-over 20 years in the electronic components industry, backed by a reliable sales team for service.
As a trusted distributor, we offer the highest quality components for a wide variety of applications. We will help you as a partner to realize your ideas. Contact us today and experience the benefits of XRS.
FAQ
Q1: How does a magnetic sensor switch operate?
Q2: How do magnetic switches differ from mechanical switches?
Q3: What advantages do magnetic switches offer?
Q4: How can I purchase magnetic switch sensor circuit from HK XRS TECHNOLOGY LIMITED?
Q5: How does HK XRS TECHNOLOGY LIMITED ensure the authenticity of products and their sources?
