TMS320 F28335
The TMS320F28335 is a 32-bit single-core microcontroller from Texas Instruments, part of the C2000™ C28x Delfino™ series. It features a 150MHz speed, 88 I/O pins, and 512KB program storage capacity. Designed for embedded applications, it operates in a temperature range of -40°C to 85°C and is available in a 176-LQFP package.
Description
Feature
High-Performance Static CMOS Technology: This circuit showcases advanced static CMOS technology, delivering outstanding performance at speeds of up to 150 MHz with a rapid 6.67-ns cycle time. Its core operates at 1.9-V/1.8-V, while the I/O design is set at 3.3V, providing a well-balanced and versatile power configuration for efficient operation.
Powerful 32-bit CPU and Integrated DMA Controller: Featuring a robust 32-bit CPU based on the TMS320C28x architecture, the chip stands out with its IEEE 754 single-precision Floating-Point Unit (FPU) in the F2833x variant. The CPU utilizes Harvard bus architecture for improved performance and supports multiple MAC operations, such as 16 × 16 and 32 × 32 MAC operations, as well as a dual 16 × 16 MAC. The chip also includes a six-channel DMA controller, which facilitates data transfers for the SARAM, XINTF, McBSP, ADC, and ePWM peripherals. This ensures effective processing and interrupt response.
Feature-Rich External Interface and High-Speed ADC: With a 16-bit or 32-bit External Interface and an extensive 2M × 16 address reach, this model offers versatile connectivity options. Up to 16 channels can be supported by its integrated 12-bit ADC, which offers an amazing 80-ns conversion rate. The XINTF allows for single or simultaneous conversions and has two sample-and-hold units and a 2 × 8 channel input multiplexer. Additionally, the chip offers versatility by allowing users to select between internal and external references, which allows it to be tailored to a variety of application needs.
Applications
1. Advanced Driver Assistance Systems (ADAS):This chip is handy in Advanced Driver Assistance Systems, particularly for medium and short-range radar applications. It helps improve safety and efficiency in cars.- 2. Building Automation:In buildings, this chip works well for controlling HVAC motors and traction inverter motors. It's great for saving energy and making systems work better.
- 3. Factory Automation & Control:For factories, this chip is good for automated sorting equipment and CNC control. It helps machines work precisely and efficiently in manufacturing.
- 4. Grid Infrastructure:In the power grid, this model is important for central and string inverters. These applications manage and convert power in the grid, showing how reliable and efficient the chip is in power infrastructure.
- 5. Hybrid, Electric & Powertrain Systems:In hybrid and electric cars, this chip does well in controlling inverters and motors. It's also used in on-board chargers (OBC) and wireless chargers, showing its flexibility in new automotive technologies.
Quality assurance
With more than 20 years of experience in the field, our company is committed to providing each and every client with high-quality electronic components. Ensuring authenticity and adhering to ethical principles of integrity, we source all of our products through authorized channels. Since we cherish every customer's trust so much, we have built enduring relationships with many of them, and they continue to put their trust in us.- In addition, we facilitate transactions through third-party platforms and perform product inspections prior to delivery upon request. Our goal is to give our customers a safe online trading environment by using secure payment methods.
About us
Leading provider of electronic components, HK XRS Technology Limited specializes in integrated circuits, LEDs, diodes, transistors, modules, capacitors, and thermistors. Our enduring client relationships are a testament to our dedication to providing exceptional quality and service. - Our commitment to delivering customized and economical quotes for specialized bill-of-materials (BOM) services is what makes us unique. Put your trust in us with your Requests for Quotations so we can work together to meet your specific needs through competitive pricing, excellent products, and individualized service.
FAQ
Q: Is it possible to substitute a different product or microcontroller for the TMS320F28335?
Q: What is the main purpose of this microcontroller, and what is it?
Q: What are this product's primary specifications?
Q: To support data storage during program execution, how much RAM is available?
Q: What is the range of operation for the voltage and how does it help with power supply configuration flexibility?
Q: How do you determine the lead time for a product?
